G-2150 Dee Shackle with Safety Bolt

G-2150 Dee Shackle with Safety Bolt is forged of high tensile steel, quenched and tempered, and has the characteristics of good toughness and durability. G-2150 Dee Shackles are used in lifting operations and static systems as removable links to connect steel wire rope, chain, and other fittings. Safety bolt shackles are used for long-term or permanent applications or where the load may slide on the pin causing rotation of the pin. G-2150 Dee(Chain) Shackles are mainly used on one-leg systems.

Product Features:

Material: drop forged high tensile steel, quenched and tempered
Safety factor: MBL equals 6 x WLL
Finish: hot dipped galvanized

Product Parameters:

g 2150 dee shackle with safety bolt 2

Size Working Load Limit
(t)
Dimensions
(mm)
Weight Each
(kg)
in mm A B D F G K M P R
1/4 6 0.5 11.9 7.85 6.35 15.5 19.1 40.4 24.6 39.6 6.35 0.06
5/16 8 0.75 13.5 9.65 7.85 19.1 25.4 48.5 29.5 46.2 7.85 0.1
3/8 10 1 16.8 11.2 9.65 23.1 31 58.5 35.8 55 9.65 0.15
7/16 11 1.5 19.1 12.7 11.2 26.9 36.1 67.5 41.1 63.5 11.2 0.22
1/2 13 2 20.6 16 12.7 30.2 41.4 77 46 71 12.7 0.34
5/8 16 3.25 26.9 19.1 16 38.1 51 95.5 58.5 89.5 16 0.67
3/4 19 4.75 31.8 22.4 19.1 46 60.5 115 70 103 20.6 1.14
7/8 22 6.5 36.6 25.4 22.4 53 71.5 135 81 120 24.6 1.74
1 25 8.5 42.9 28.7 25.4 60.5 81 151 93.5 135 25.4 2.52
1-1/8 29 9.5 46 31.8 28.7 68.5 91 172 103 150 31.8 3.45
1-1/4 32 12 51.5 35.1 31.8 76 100 191 115 165 35.1 4.9
1-3/8 35 13.5 57 38.1 35.1 84 111 210 127 183 38.1 6.24
1-1/2 38 17 60.5 41.4 38.1 92 122 230 137 196 41.1 8.39
1-3/4 45 25 73 51 44.5 106 146 279 162 230 54 14.2
2 51 35 82.5 57 51 122 172 312 184 264 60 21.2
2-1/2 63 55 105 70 66.5 145 203 377 238 344 66.5 38.6
3 76 85 127 82.5 76 165 216 429 179 419 89 56
